DMM7560 Yokogawa
Multimeters and Voltmeters
Benchtop multimeter, 6 1/2 digits, 4.3″ color graphic display, USB 2.0 as standard & GP-IB, LAN, RS-232 as an option.
| RENTAL | 235 € /week* | ||||
| SALE |
|
||||
Specifications : DMM7560 Yokogawa
Programmable 6 1/2 digit benchtop multimeter :
- Resolution: 6½ digits.
- Sampling rate : up to 30 kS/s,
- DC accuracy : 0.0035% + 0.0005% (10 V range),
- DC/AC voltage : 100 mV to 1000 V.
- DC/AC current : 1 mA to 3 A,
- Resistance : ratings 100 Ω to 100 MΩ,
- Frequency range : 3 Hz to 300 kHz,
- Temperature : thermocouples and RTD,
- Internal memory : 100 k points,
- Interfaces : USB 2.0 as standard & GP-IB, LAN, RS-232 optional,
- 4.3″ color graphic screen.
- Mathematical functions : statistics, limits, scaling,
- Graphical displays : trend, histogram, analog,
- Integrated datalogger,
- Dimensions : 225 x 100 x 366 mm,
- Weight : 3 kg.
Download the technical documentation DMM7560 Yokogawa
You need to be connected to consult and download the documentation
Create my account / Connexion
The DM7560 multimeter is a high-performance benchtop digital multimeter offering excellent measurement accuracy and stability.
With its 6½-digit resolution and high sampling rate of up to 30,000 points per second, it meets the needs of the most demanding test and measurement applications.
Its large 4.3″ color screen provides clear visualization of measurements and allows you to display trend graphs and histograms in real time.
Versatile, the DM7560 multimeter has multiple communication interfaces for easy integration into automated test systems.
