TSG4104A Tektronix
RF Signal Sources
True DC to 4 GHz to support both analog and vector/digital signal generation, USB, GP-IB, RS-232, and LAN interfaces.
| RENTAL | 590 € /week* | |||||||
| SALE |
|
|||||||
Specifications : TSG4104A Tektronix
Excellent and compact Digital RF signal generator :
- True DC to 4 GHz to support both analog and vector/digital signal generation,
- Typical ±0.30 dB amplitude accuracy (0 dBm CW signal at 22 ∫C) from 10 MHz to 2 GHz,
- Modulation applications for GSM, EDGE, W-CDMA, APCO-25, DECT, NADC, PDC, and TETRA,
- Soft key upgrade to vector/digital modulation at very low cost,
- Analog and vector/digital signal generation capabilities,
- Dual baseband ARB generators,
- Analog modulation standard, I/Q modulation inputs (400 MHz RF bandwidth),
- ASK, FSK, MSK, PSK, QAM, VSB, and custom I/Q,
- Standard OCXO,
- Output level : +25 dB to -130 dB,
- USB, GP-IB, RS-232 and LAN interfaces.
Download the technical documentation TSG4104A Tektronix
You need to be connected to consult and download the documentation
Create my account / Connexion
The TSG4100A Series RF Vector Signal Generator offers mid-range performance and up to 200 MHz modulation bandwidth at an entry-level RF signal generator price.
They use a new technique to provide spurious free outputs with low phase noise (-113 dBc/Hz at 20 kHz offset from 1 GHz carrier) and extraordinary frequency resolution (1 μHz at any frequency).
The TSG4100A Series comes standard with analog modulation.
TSG4102A DC/950 kHz to 2.0 GHz
TSG4104A DC/950 kHz to 4.0 GHz
TSG4106A DC/950 kHz to 6.0 GHz
