NGC102 Rohde & Schwarz
DC Power Supplies
2-Ch DC Power supply, 0-32 V, 0-5 A, 100 W (total), programmable USB/LAN, GP-IB for G models.
| RENTAL | 69 € /week* | ||||
| SALE |
|
||||
Specifications : NGC102 Rohde & Schwarz
2-Ch High Quality an compact DC power supply :
- Voltage : 0-32 V,
- Current : 0-5 A,
- Max power : 100 W. (RMS) / <4 mV (peak to peak),
- Charge recovery time : < 1ms (meas.) – Charge variation from 10% to 90%,
- Programming resolution : 1 mV/0.1 mA,
- Feedback resolution : 1 mV/0.1 mA,
- Feedback accuracy : <0.05% + 2 mV | <0.05% + 4 mV/<0.05% + 2 mA,
- Protection functions : OVP/O99/OCP/OTD,
- Arbitrary output ramp/function,
- Remote detection / channel sequencing,
- Data logging/external triggering,
- Remote control interfaces : USB/LAN, GP-IB (G models)
- Screen : 3.5″ / QVDA.
OTHER MODELS :
- NGC101 : 100 W DC power supply (32 V/10 A), 1 channel.
- NGC101-G: 100 W DC power supply (32 V/10 A), 1 channel + GPIB.
- NGC102-G: 100 W DC power supply (32 V/5 A), 2 channels + GPIB.
- NGC103: 100 W DC power supply (32 V/3 A), 3 channels.
- NGC103-G: 100 W DC power supply (32 V/3 A), 3 channels + GPIB.
Download the technical documentation NGC102 Rohde & Schwarz
The Rohde & Schwarz NGC100 power supply series includes one-, two-, and three- Channels models that provide up to 32 V, 10 A, and 100 W, providing exceptional versatility in various applications from development labs to industrial environments.
The outputs are galvanically isolated, floating and protected against overloads and short circuits. Electrically equivalent outputs on two- and three-channel models allow users to connect multiple outputs in parallel or series to increase voltage or current up to 96 V or 10 A.
Synchronizing outputs, running waveform tests, and recording data for in-depth analysis becomes easy with this series of power supplies.
An intuitive operating concept allows the user to quickly navigate the menus.
All NGC100 power supplies are equipped with remote sensing terminals, external trigger input, analog control interface, USB, LAN and GP-IB interface for G models.
