NGA141 Rohde & Schwarz
DC Power Supplies
R&S NGA41, One output, Max. 40 W, Max. 100 V or max. 2 A, USB, Ethernet interfaces, Wireless LAN (WLAN).
| RENTAL | 58 € /week* | ||||
| SALE |
|
||||
Specifications : NGA141 Rohde & Schwarz
NGA100 Power Supply Series, Linear, Accurate, Affordable :
- NGA101, One output, Max. 40 W, Max. 35 V or max. 6 A,
- NGA102, Two outputs, Max. 80 W, Max. 35 V or max. 6 A per output, Max. 70 V in serial or max. 12 A in parallel,
- NGA141, One output, Max. 40 W, Max. 100 V or max. 2 A,
- NGA142, Two outputs, Max. 80 W, Max. 100 V or max. 2 A per output, Max. 200 V in serial or max. 4 A in parallel mode.
- Linear design,
- High readback accuracy, Color coding,
- Built-in statistics,
- Independent channels,
- FlexPower,
- Safety binding posts,
- Rackmountable
- Full-featured,
- EasyRamp, EasyArb, Data logging,
- Low-current measurement range,
- Channel fusion, Tracking,
- Remote sensing,
- Save/recall device settings, Protection functions,
- USB, Ethernet interfaces, Wireless LAN (WLAN),
- Digital trigger I/O.
Download the technical documentation NGA141 Rohde & Schwarz
The R&S®NGA100 power supplies are linear, compact and easy to use. All models have excellent readback accuracy with a low-current range for demanding measurements.
Features such as data logging, arbitrary waveforms, built-in statistics and remote sensing make the instruments ideal for various bench applications.
Equipped with a number of different remote interfaces, including USB and Ethernet, the R&S®NGA100 power supplies are also great for automated tests.
The channel fusion feature extends voltage and current range. Get up to 200 V with the NGA142 in serial mode and up to 12 A with the NGA102 in parallel mode.
Advanced protection functions keep devices connected and power supplies safe.
