RTO2064 Rohde & Schwarz

Oscilloscopes > 3 GHz

High-end Digital Oscilloscope 6 GHz, 4 Ch, 20 Gsample/s.



RENTAL 1 375  /week*
SALE
New price Warranty 36 month 49 830

Set your quotation

Choice of delivery *

Options preference

Enter all the available options you want to add, separated by commas.

Quantity

Specifications : RTO2064 Rohde & Schwarz

High-end Digital Oscilloscope 6 GHz, 4 Ch :

  • 20 Gsample/s,
  • Acquisition memory : 50 Msample per channel, max 2 G sample,
  • Acquisition rate : 1 million waveforms per second,
  • Up to 16-bit vertical resolution,
  • Integrated spectrum analysis,
  • High-resolution 12,1” capacitive touchscreen with gesture support,
  • Offer a complete multi-domain test solution (protocole tester),
  • 16 digital channels (option),
  • High dynamic range and sensitivity EMI debugging,
  • Vector signal explorer software (see options),
  • 100 MHz function generator, arbitrary waveform generator and eight-channel pattern generator,
  • 1 Gbps LAN, type A: 2 × USB 3.1, 2 × USB 2.0, type B: 1 × USB 3.1, GP-IB (optional), DVI and display port for external monitor, external trigger, trigger output.

Available options RTO2064 Rohde & Schwarz

CAL Standard Calibration 1 450
B4 OCXO 10 MHz 1 310
B6 Arbitrary Waveform Generator 2 analog & 8 digital Ch 1 550
B110 Memory upgrade 1 Gs/s 15 650
K11 I/Q Sofware Interface 2 990
K18 Multi-Channel Spectrum analysis 2 420
K31 Power Analysis 2 110
K134 Advanced Jitter and Noise Analysis 7 770
RT-ZS60 Active Voltage Probe 6 GHz 1 Mohm, 0,3 pF 6 410
RT-ZD40 Differential Active Probe 4,5 GHz 1 Mohm 0,4 pF 7 320

Download the technical documentation RTO2064 Rohde & Schwarz

You need to be connected to consult and download the documentation

R&S®RTO oscilloscopes combine excellent signal fidelity, up to 16-bit vertical resolution and high acquisition rate in a compact device format in the 600 MHz to 6 GHz class. They offer a fully integrated multi-domain test solution with frequency, protocol and logic analysis functions. The brilliant touchscreen makes the oscilloscopes very comfortable to use.
