NHT-3D Microrad

EMC Measurement - GPS

The NHT-3D is a high-performance portable analyzer designed for electric and magnetic field measurements characterized by complex or impulsive form factors (weighted peak method).

RENTAL 211  /week*
SALE
New price Warranty 24 month 7 450

Specifications : NHT-3D Microrad

The NHT-3D is a high-performance portable analyzer designed for electric and magnetic field measurements characterized by complex or impulsive form factors (weighted peak method):

  • Frequency range 0 Hz – 400 KHz and broadband: 100 kHz – 40 GHz,
  • Time domain analyzer,
  • Frequency domain analysis (real-time FFT up to 65,536 samples),
  • Dynamic range > 100 dB,
  • Selectable index available on the device:
    WP10 – Weighted Peak (according to Icnirp 2010 Health Physics 99:818-836-2010), IB50 (Time domain Analysis CEI EN 62233),
  • Index selectable via software:
    WP10 – Weighted Peak (Icnirp 2010 Health Physics 99:818-836-2010),
    II98 (Icnirp 1998 Health Physics 74: 494-522-1998),
    IB50 (Time domain Analysis CEI EN 62233),
    IRSS (CIS Frequency Domain Analysis IN 62233),
  • Computing and displaying RMS, IRMS, Max, Min, Instant, Max F
  • Displaying safety threshold limits according to current standards,
  • GPS receiver and temperature sensor,
  • Interchangeable probes,
  • Li-ion battery power with more than 24 hours of battery life,
  • Backlit screen,
  • Fibre-optic communication (up to 40 m).

Available options NHT-3D Microrad

CAL Standard Calibration 745

Download the technical documentation NHT-3D Microrad
