34970A/001 Keysight / Agilent
Acquisition
Data Acquisition/Switch Unit, up to 120 Channels, 8 available different Plug-In, see Agilent series 34901A to 34908A, Built-in GPIB and RS-232 interfaces.
| RENTAL | 115 € /week* | |||||||||||
| SALE |
|
|||||||||||
Specifications : 34970A/001 Keysight / Agilent
Programmable Data Acquisition/Switch Unit without multimeter :
- 8 switch and control plug-in modules to choose from, temperature with thermocouples, RTDs,
and thermistors, dc and ac volts, 2- and 4-wire resistance,frequency and period, dc and ac current, - 3-slot mainframe offers up to 96 matrix crosspoints or 120 single-ended channels,
- HP BenchLink Data Logger software included, drivers available for Agilent VEE and National Instruments LabVIEW®,
- 50k readings of non-volatile memory holds data when power off,
- Built-in GPIB and RS-232 interfaces.
Download the technical documentation 34970A/001 Keysight / Agilent
