JD745A JDSU
Telecom Test Equipement
Base Station Analyzers serie, 100 KHz to 4 GHz.
| RENTAL | 590 € /week* | |||||||
| SALE |
|
|||||||
Specifications : JD745A JDSU
Base Station Analyzers serie :
- Spectrum analyzer 100 kHz to 4 GHz (JD745A), 9 kHz to 8 GHz (JD785A),
- Cable and antenna analyzer 5 MHz to 4 GHz (JD745A), 5 MHz to 6 GHz (JD785A),
- RF power meter,
- Built-in preamplifier,
- 2-port transmission measurements (option 001),
- Bias tee (option 002),
- CW signal generator (option 003),
- E1/T1 analyzer (option 004, 005),
- Bluetooth connectivity (option 006),
- GPS receiver and antenna (option 010),
- Interference analyzer (option 011),
- Channel scanner (option 012),
- Optical power meter (options 020 to 029), via an optical power sensor (MP-60A or MP-80A),
- Signal analyzer (options 020 to 029),
- Over-the-air analyzer (options 040 to 049),
- AM/FM audio demodulation,
- Route map,
- PIM detection,
- Dual spectrum,
- Up to six markers and six traces,
- Communicates with the analyzer via LAN or USB,
- Bluetooth connectivity (option 006),
- Modulation analysis :
• cdmaOne/cdma2000 (option 020)
• EV-DO (option 021)
• GSM/GPRS/EDGE (option 022)
• WCDMA/HSPA+ (option 023)
• TD-SCDMA (option 025)
• Mobile WiMAX (option 026)
• LTE-FDD (option 028)
• LTE-Advanced—FDD (option 030)
• LTE-TDD (option 029)
• LTE-Advanced —TDD (option 031)
Over-the-air (OTA) analyses include:
• cdmaOne/cdma2000 (option 040)
• EV-DO (option 041)
• GSM/GPRS/EDGE (option 042)
• WCDMA/HSPA+ (option 043)
• TD-SCDMA (option 045)
• Mobile WiMAX (option 046)
• LTE-FDD (option 048)
• LTE-TDD (option 049)
The price is given as an indication, please contact us for a ReNEWed® offer with the desired options.
Download the technical documentation JD745A JDSU
You need to be connected to consult and download the documentation
Create my account / Connexion
A CellAdvisor JD745A/JD785A Base Station Analyzer is the optimal test tool for installing and maintaining cell sites.
It contains all the features and capabilities required for field testing cell sites for all 2G to 4G wireless technologies.
Equipped with one-button standards-based measurements for wireless signals, the analyzer offers a full scope of BTS conformance
tests.
Its combined functionality includes spectrum analysis, cable and antenna analysis, an RF/optical power meter, interference analysis, a
channel scanner, E1/T1 analysis, and signal analysis.
