7815 Itech
AC power
7815 Compact 3U Only AC + DC power supply, 15 KW, 90 A, color touch LCD screen, LAN / USB / CAN, GPIB / RS232 interfaces and optional analog control.
The rental period for this item is set at a minimum of 15 days for preparation and logistical reasons.
| RENTAL | 745 € /week* | |||||||
| SALE |
|
|||||||
Specifications : 7815 Itech
7815 Compact AC + DC Power Supply Series :
- Programmable frequency: 16 to 2400 Hz,
- 30 A to 90 A,
- Power : 3 kVA to 15 kVA,
- Touchscreen LCD,
- Oscilloscope function,
- Display of Vrms, Irms, Frequency, PF, active & apparent power,
- Disturbance simulation,
- Start and stop on phase angle from 0 to 360°,
- Harmonic analysis down to the 50th order,
- Master/slave operation for increased power,
- Sense input,
- Standard interfaces: LAN / USB / CAN, GPIB / RS232 and optional analog control.
Download the technical documentation 7815 Itech
The ITECH IT7800 series AC/DC power supplies combine intelligence and modularity in a minimal footprint.
In a 3U form factor with a power rating of 15 kVA, they offer considerable space savings in the test lab.
They can be used in parallel, in master/slave mode, up to a power rating of 960 kVA.
Their touchscreens and intuitive interfaces allow users to quickly become familiar with their operation.
The four operating modes—AC, DC, AC+DC, and DC+AC—ensure you can perform the most demanding AC tests.
For applications requiring more than 350 V, the phase reversal function allows you to double the output voltage.
The IT7800 series integrates a wattmeter and an arbitrary waveform generator capable of simulating any waveform. On three-phase models, the outputs can be connected in parallel, providing a higher-power single-phase output.
The multi-channel function allows you to test three devices simultaneously and completely independently.
Waveforms are directly viewable on the large touchscreen accessible on the front panel.
The wattmeter function, including harmonic analysis up to the 50th harmonic, ensures precise signal analysis without the need for additional equipment.
