GL2000 Graphtec

Plotters - Loggers

Graphic recorder 4 isolated channels, 600 Vdc and true RMS, CAT III, Universal inputs, voltages / thermocouples, pulse counting, logic channels, alarm outputs, Large 177 mm LCD display, Sampling 1 Ms/s on each channel, Speed 1 µs per channel simultaneously, 16-bit resolution, Direct visualization in XY mode, many triggering modes, USB 2 and Ethernet interfaces, … Read more

RENTAL 86  /week*
SALE
New price Warranty 24 month 2 490

Specifications : GL2000 Graphtec

  • Graphic recorder 4 isolated channels, 600 Vdc and true RMS, CAT III,
  • Universal inputs, voltages / thermocouples, pulse counting, logic channels, alarm outputs,
  • Large 177 mm LCD display,
  • Sampling 1 Ms/s on each channel,
  • Speed 1 µs per channel simultaneously,
  • 16-bit resolution,
  • Direct visualization in XY mode, many triggering modes,
  • USB 2 and Ethernet interfaces,
  • Internal RAM memory of 4 million points, internal non-volatile flash memory of 4GB,
  • Storage on USB key or external SD card,
  • Optional thermal printer.

Available options GL2000 Graphtec

CAL Standard Calibration 275
PC-1450 Valise de transport rigide, étanche (IP 67), antichocs 245
B-569 Batterie interne DC 7.2V, 2900 mAh 185
B-514 Câble d'alimention DC 45
DP-581H Imprimante thermique USB batterie 2 500

Download the technical documentation GL2000 Graphtec

You need to be connected to consult and download the documentation

The Graphtec GL2000 at a glance :

The Graphtec brand is well known for its reliable and easy-to-use stand-alone recorders.

The GL2000 from Graphtec is an economical, high performance and autonomous recorder equipped with 4 isolated CATIII 600V channels.

Chassis equipped with a 177 mm color LCD screen. Fast recording 1 Ms/s per channel simultaneously, 16-bit resolution.

USB 2 and Ethernet interfaces, internal RAM memory of 4 million points, internal non-volatile flash memory of 4GB, storage on USB key or external SD card.

Leasametric offers this recorder Graphtec GL2000 for sale and rental. Moreover, thanks to its ISO 9001 certified laboratory, Leasametric can calibrate this instrument.

More information available on the datasheet in PDF format
