63212A/150-1200 Chroma

Dynamic Loads

Chroma 63200 serie, Programmable DC Electronic Load, model 63212A/150, 0-150 V, 0-1200 A, 12 kW.

RENTAL 1 125  /week*
Brand New Price Warranty 24 month 26 420

Set your quotation

Choice of delivery *

Options preference

Enter all the available options you want to add, separated by commas.


Specifications : 63212A/150-1200 Chroma

Chroma 63200 serie, Programmable DC Electronic Load, model 63212A/150, 0-150 V, 0-1200 A, 12 kW :

  • Rated power serie : 2 kW, 3 kW, 4 kW, 5 kW, 6 kW, 8 kW, 10 kW, 12 kW, 15 kW, 18 kW, 20 kW, 24 kW, max. 240 kW (parallel),
  • Voltage range: 60V, 150V, 600V, 1200V,
  • Current range: 2,000A max. per unit,
  • CC, CR, CV & CP operation modes,
  • CR+CC, CR+CV, CC+CV complex modes,
  • Up to 10 units master/slave parallel control,
  • Dynamic synchronous control in static and dynamic loads,
  • User defined waveform (UDW),
  • CZ mode for turn on capacitive load simulation,
  • External loading current simulation,
  • Auto frequency sweep up to 50 kHz,
  • Real time power supply load transient response simulation & Vpk+/- measurement,
  • User programmable 255 sequential front panel input status,
  • Ultra high precision voltage & current measurement,
  • Precision high speed digitizing measurement/data capture,
  • Voltage, current & Pmax measurement for OCP/OLP tesing,
  • Timing & discharging measurement for batteries,
  • Instant overpower loading,
  • Short circuit simulation,
  • Smart fan control,
  • Full protection : OC (adjustable), OT, OP (adjustable) protection & OV warning,
  • Standard USB, optional Ethernet and GP-IB interfaces.

Available options 63212A/150-1200 Chroma

CAL Standard Calibration 995

Download the technical documentation 63212A/150-1200 Chroma

You need to be connected to consult and download the documentation

The 63200A series high power DC electronic loads are designed for testing a wide range of power conversion products including AC/DC
and server power supplies, DC/DC converters, EV batteries, automotive charging stations, and other power electronics components.

These units can be synchronously paralleled up to 240 kW and dynamically synchronized for generating complex multi-channel transient
profiles. The 300% peak overpower capability provides extra headroom for fault condition simulations in automotive batteries, fuel cells,
and more.
