CA6160 Chauvin Arnoux

Electrical Safety tester :

• One box instrument for all testing,
• Dielectrical testing, voltage drop and continuity testing,
• Insulation resistance measurement,
• Leakage current measurement,
• Discharge time measurement and functional testing,
• Mains voltage :230V/50-60Hz, 500 VA max,
• Permanently backlit LCD matrice screen,
• RS-232 Interface,
• Remote control signals :ON/OFF, RECORD,
• Connector for connection with EAN13 type bar code reader,
• Comply with EN 61010-1 and EN 61326 standards,
• Overvoltage category : Cat .III 300 V,Cat.II 600 V,
• Protection factor (closed) :IP 50,
• Dimensions : 410 x 175 x 370 mm,
• Weight : 13.5 kg (C.A 6160).
