HPS20K800 BK Precision
DC Power Supplies
Programmable DC power supply 20 kW, DC to 800 V, 25 A, solar panel simulation, RS-232 and LAN interfaces.
| RENTAL | 745 € /week* | |||||||
| SALE |
|
|||||||
Specifications : HPS20K800 BK Precision
High power programmable DC power supply :
- 0 to 800 V and 25 A per unit,
- 5-inch TFT touchscreen for intuitive control,
- High power density, 20 kW in a 3U format,
- Yield up to 94%,
- Integrated measurement of voltage and current,
- Master/slave mode provides up to 160 kW of output power with 8 units connected in parallel,
- Galvanically isolated analog control and monitoring interface,
- OVP, OCP, OPP, UVP (undervoltage protection) and key lock functions,
- Configurable voltage and current rise times,
- Fast response time to transients < 3 ms,
- Thermostatically controlled fans to minimize noise,
- Simulation of the production of photovoltaic panels,
- Remote detection to compensate for voltage drop,
- Saving data directly to a USB key,
- Output on / off timer,
- RS-232 and LAN interfaces,
- LabVIEW™ drivers included,
- Three-phase 208 VAC or 400 VAC input configurations available (factory configuration).
Download the technical documentation HPS20K800 BK Precision
You need to be connected to consult and download the documentation
Create my account / Connexion
HPS Series programmable DC power supplies provide 20 kW of clean output power and high efficiency in a compact 3U form factor.
These power supplies are well equipped for ATE system applications requiring a wide output voltage up to 1500 V.
Multiple power supplies can be combined in parallel to increase the total power output up to 160 kW.
Applications
- Testing photovoltaic components, including inverters and battery charge controllers,
- Relay and component testing,
- Various applications in the aerospace, electric vehicle and green technology sectors,
- Manufacturing and production tests.
