4088 BK Precision

RF Signal and Waveform Generators :

• RF Signal
  RF signal frequency up to 1.5 GHz/3 GHz,
  0.1 Hz resolution, 11 digits,
  Frequency characteristics: ± 3 ppm accuracy, ± 1 ppm stability, 0.1 Hz resolution,
  Amplitude range from -110 dBm to +13 dBm,
  Phase noise < -117 dBc/Hz,
  Internal or external AM/FM/PM and pulse modulation functions,
  Protection against reverse power up to 30 V DC or +25 dBm RF power.
• Signal Generator / AWG
  16-bit resolution, 250 MSa/s, arbitrary waveform generator with up to 4 Mpts,
  Generates sine and square waves from 1 µHz to 80 MHz,
  Generates triangle/ramp waves up to 5 MHz and pulse signals up to 10 MHz,
  Amplitude up to 10 Vpp into a 50 Ω load or up to 20 Vpp in an open circuit,
  12 built-in arbitrary waveforms,
  Internal or external modulation functions: AM, FM, PM, PWM, BPSK, and FSK,
  Continuous, gated, burst, and triggered modes,
  Linear and logarithmic sweeping,
  Variable DC offset ± 5 V,
  Low jitter < 25 ps,
  Internal/external triggering and programmable markers.
• General
  4.3-inch LCD screen featuring IPS technology for wider viewing angles,
  Internal memory for saving and recalling up to 99 instrument configurations,
  Standard USB and LAN interfaces; optional GP-IB,
  LabVIEW™ driver provided,
  Supports industry-standard SCPI commands.
